SL7-63 MCB Circuit Breaker

Name: SL763 MCB Circuit Breaker
Brand: Suntree /OEM
Price: 3.40 USD

Wholesale SL7-63 MCB Circuit Breaker from china suppliers

Brand Name : Suntree /OEM

Model Number : SL7-63

Certification : EN/IEC60898

Place of Origin : Zhejiang, China

MOQ : 30 Piece/Pieces

Price : $3.40 - $15.00 / Piece

Supply Ability : 10000 Piece/Pieces per Month

Packaging Details : standard packing

Type : Mini, ac type circuit breaker

Poles Number : 1,2,3,4

Rated Current(A) : 1~63A

Rated Voltage(V) : 250/415V

Breaking capacity : 4.5kA~6kA

Pole : 1P,2P,3P,4P

Characteristic Curve : B,C,D

Frequency : 50/60Hz

Mechanical Life : 10000 Times

Warranty : 2 years

Port : NINGBO/SHANGHAI

Contact Now

professional design ac type circuit breaker mini breaker mcb price

Product Description

SL7-63 have protective function as shotrage as overload, and are used in lighting distribution systen in connerce and dwelling, and protrect fractional electric motors. and they also have many merits of high protective grade(up to IP20), high breaking capacity, reliable sensutive action, convenient, multi pole assemnling, long life ect.

They are mainly adapted to the circuit of AC 50Hz, 250V in single pole, 415V in double, threee, four poles for protecting overload abd short circuit. Mean while, ther are also used in turning on or off the electric apparatus and lighting circuit under the normal conditions.

Product Parameters

Product Type	SL7 Series
Standard	EN60898(IEC60898);IEC60947-2
Rated Current	1/2/3/4/6/10/16/20/25/32/40/50/63A
Rated Voltage	230V/250V/400BV/415V
Pole	1P/2P/3P/4P
Rated Breaking Capacity	4.5kA IEC60898(0.5-63A)
	6kA IEC60947-2(0.5-63A)
Characteristic curve	B,C,D
Max.fuse that can be connected to	100AgL>10kA
Selective grade	3
Working ambient temperature	-5°C-- +40°C
Enclosed protective class	IP20
Electrical life	Not less than 8000 times
Mechanical life	Not lesss than 20000 times

SL7-63 MCB Circuit Breaker

Detailed Images

Company Profile

XinChi Electric Group Co., Ltd is a group company,There are four branch companies subordinate to it. Registered trademark is "suntree".

Main Products: AC&DC Circuit breaker, Solar system parts,SISO-40 Solar Inverter/Cable

,Connector,Contactors, MCCB, ATS auto transfer switch, DC Combiner Box, Waterproof distribution box,etc.

Quality &Standards:Products are producted per ISO9001:2008, IEC60947, IEC60898,CB, SAA, TUV,CE,SONCAP,ROHS, Nemko, PCT,CCC etc

Main markets:Australia,New Zealand,&other worldwide markets

FAQ

Q: How can i trust you and your company ?

A: Suntree is a group company, we have 6 subcompanies. Have cooperation with LS, EKF the world-class companies. Our company over 500 employees, products pass CE,IEC,TUV,SAA, RCM, ROHS certificates.

Q: How long is your products warranty ?

A: The warranty period of our products is 2 Years.

Q: How about inspection?

A: We have the whole inspection system from raw material to end products include Transient test, delay test,mechanical life test and so on.

Q: What is the service offered by company?

A: We have the professional enginer team which can design and develop the mold to arrive different customer requirement.

We also have the sales team to offer good service from pre-sale to after-sale.
